3 AIs Design API-Led Connectivity in MuleSoft: Claude vs CurieTech vs MuleSoft Vibes

Three AIs. One MuleSoft architect brief. Zero human code.

I handed Claude, CurieTech AI, and MuleSoft Vibes the exact same prompt — design a 3-layer API-led connectivity network for a Customers + Orders domain — and let each one build the whole thing on its own. Then I scored the results the way I’d review a real submission: contract-first design, business rules, error handling, tests, and version hygiene.

This is Round 2 of AI Showdown: MuleSoft Edition (2026) 🥊. Round 1 pitted two AIs against DataWeave puzzles; this time the task is a full API-led topology, and there’s a third contestant in the ring.

Every solution is in the GitHub repo: 🔗 github.com/alexandramartinez/ai-showdown-api-led

TL;DR

All three built the three layers (Experience → Process → System) and implemented all 11 operations. The differences were in the engineering discipline underneath:

• Claude (Opus 4.8, MAX effort) was the most disciplined build — contract-first RAML, a parent reactor POM, and the only solution whose data survives a restart. Its weak spot: the oldest runtime of the three.
• CurieTech AI was the most complete and granular — five apps split per entity, the most tests (41 MUnit cases), the richest error handling, and a dedicated status endpoint. Its weak spot: version drift across those five apps with no central POM.
• MuleSoft Vibes (Sonnet) was a fast, runnable demo on the freshest connectors — but no API specs, no APIkit, no tests, no error handler, no docs, and writes don’t persist.
• None of the three added a security layer, and none used the true latest Mule runtime.

The brief

The prompt asked each AI to think like a MuleSoft architect and build an API-led connectivity example with all three layers for a Customers + Orders domain. The ground rules:

• Three layers: Experience, Process, System.
• Mock and seed test data in the System layer, as if it were wired to a real database (no actual DB connection yet).
• At least 3 APIs (one per layer) — split further if it makes architectural sense, but don’t build one giant do-everything API and don’t repeat code.
• Use the latest Mule, Maven, and DataWeave versions.

And the 11 operations the network had to cover:

1. List all customers
2. Get one customer’s details
3. Get a customer’s orders
4. Get one order’s details
5. Create a customer
6. Edit a customer
7. Delete a customer only if they have no orders
8. Create an order attached to a customer
9. Edit an existing order
10. Cancel an order (a status change, not a delete)
11. Delete an order

Two of those are business-rule traps on purpose: #7 (block the delete when orders exist) and #10 (cancel ≠ delete).

The contestants

• 🟦 Claude — Opus 4.8, MAX effort
• 🟨 CurieTech AI — model undisclosed
• 🟩 MuleSoft Vibes — Sonnet (effort unknown)

The scorecard

🟦 Claude: the most disciplined build

Claude produced four apps and, crucially, wired them together with a parent reactor POM so every app inherits the same dependency versions from one place. That’s the single move that separates “four Maven projects in a folder” from “a governed project.”

It went contract-first: RAML 1.0 specs for every app, scaffolded with APIkit, with all 11 operations defined in the spec and implemented. Error handling is a global handler in all four apps covering 400/404/409, plus a 500 trait in the spec.

The standout: Claude added the File connector to the System layer, so seeded data actually persists across restarts. It’s the only one of the three where you can POST a customer, restart the app, GET it back, and it’s still there. Both business-rule traps are handled — a 409 when you try to delete a customer with orders, and a status flip to CANCELLED for cancel-vs-delete.

The catch: it shipped on Mule 4.9.0, the oldest runtime of the three, with the oldest plugin versions to match. Rock-solid, slightly behind.

🟨 CurieTech AI: the most complete and granular

CurieTech went the furthest on topology — five apps, splitting both the Process and System layers per entity (customers vs. orders). That granularity paid off in coverage: 41 MUnit tests (more than double Claude’s), the richest error handling of the three (including proper 502 gateway semantics between layers), and the cleanest take on the cancel rule — a dedicated PATCH /orders/{id}/status endpoint instead of overloading a PUT.

It also nailed the seed-data detail that tests the business rules: 8 seed orders across 5 customers, with one customer (CUST-005) deliberately left order-free so you can actually exercise the “delete only if no orders” path.

The catch: with five independent apps and no parent POM, versions drifted. The runtime ranged from 4.9.3 to 4.11.3 across apps, and APIkit/MUnit/HTTP-connector versions were similarly spread. Data lives in ObjectStore, so it persists across requests but is lost on restart. Feature-complete and well-tested — just missing the central version governance a parent POM gives you for free.

🟩 MuleSoft Vibes: a fast, runnable demo

MuleSoft Vibes produced something that runs and uses the freshest connectors — it was the only contestant on the current HTTP connector (1.11.3) — with consistent versions across its four apps.

But it skipped most of what makes API-led API-led: no RAML specs, no APIkit (hand-rolled HTTP listeners instead), no MUnit tests, no global error handler, and no docs. The operations are all coded and return the right status codes, but the data is read-only — a GET right after a POST returns a 404 for the record you just “created,” because nothing actually persists.

The business-rule logic is correct on paper; it just runs against data that never changes. Great for a quick “look, it works” demo — not something you’d hand to a team.

The version reality check

The brief said “use the latest.” Nobody fully did — and it’s a useful reminder that AIs anchor to whatever versions dominated their training data, not to what shipped last week.

All three picked real, released versions and correctly used Java 17 — no hallucinated version numbers, which is genuinely reassuring. But none reached Mule 4.12.0, and the plugin versions trailed further behind than the runtimes did. If you’re using an AI to scaffold a project, pin your versions yourself.

The gap all three left

Every contestant skipped a security layer entirely — no client-ID enforcement, no policies, nothing gating the Experience API. The brief didn’t explicitly ask for it, but “think like a MuleSoft architect” arguably should have surfaced it. It’s the clearest example of AIs doing exactly what’s asked and no more: none of them pushed back with “you probably also want auth here.”

So who wins?

Depends on what you’re optimizing for:

• Want a foundation to build on? 🟦 Claude. The parent POM and real persistence mean you can hand this to a team and extend it without fighting version chaos.
• Want the most coverage and granularity out of the box? 🟨 CurieTech AI. More tests, more error handling, a cleaner status endpoint — just add a parent POM and reconcile versions.
• Want a quick runnable demo to show the shape of API-led? 🟩 MuleSoft Vibes. Fastest to something that runs, as long as you don’t need it to remember anything.

The meta-takeaway: all three are genuinely useful scaffolding tools, and all three need a human architect to close the same gaps — security, version pinning, and (for two of them) persistence. AI gets you to a working three-layer network fast. It doesn’t yet get you to production.

What’s next?

AI Showdown: MuleSoft Edition (2026) is an ongoing series comparing AI coding tools on the same MuleSoft and DataWeave challenges. Round 1 was DataWeave puzzles; this was API-led architecture.

🎯 What should the next round test — and which AI should join the ring? Drop a comment on YouTube or reply to this post.

🔔 Subscribe so you don’t miss the next round: youtube.com/prostdev
