Agentforce Voice: Let Callers Type Their Email Mid-Call

Have you ever tried to spell your email address to a voice agent? “C as in cat, H, R…” and then it reads back something completely different. Email addresses, name spellings and booking codes are some of the hardest things for a voice agent to hear correctly.

Typeback is a pattern I built for Agentforce Voice to fix that: when the caller wants something emailed, the agent makes a link to a one-field form instead of asking them to spell it. The caller types the email on their phone, says “done”, and the agent reads back a masked hint (“starting with C, at example dot com”) on the same call. The agent’s language model never sees the full email.

In this tutorial I’ll walk you through every step to rebuild it in your own Salesforce org, in order, plus every problem I hit along the way and how I fixed it. You can follow it by hand, or hand it to an AI coding agent and do only the steps that need a person.

TL;DR

• You’ll build a phone number that reaches an Agentforce Voice agent (a resort concierge) that captures the caller’s email through a form link instead of speech.
• The code (Apex, a Lightning Web Component form, an Agent Script agent and setup scripts) is in the agentforce-typeback GitHub repo. Most steps are one script.
• The Setup click paths (site activation, phone number, Omni-Channel flow, voice channel) have to be done by a person.
• The full loop works on a live call from a mobile phone. What’s not done: texting the link automatically. For now the link reaches the phone by hand.
• Every gotcha I hit is in the troubleshooting tables at the end.

What you’ll build

Here’s how a call flows from the caller’s phone to the agent and back, one step at a time:

1. The call reaches the agent. The caller dials the phone number. An Omni-Channel flow with a single Route Work element sends the call to TypebackDemoVoice, the Agent Script agent.
2. The caller asks for an email. For example: “Can you email me my booking confirmation?”
3. The agent makes a link. TypebackRequestAction creates a random token and saves only its hash on a new Typeback_Request__c record with the status Pending. Then it hands the link to the sender.
4. The link reaches the caller’s phone. For now, the Log sender saves the link on the record (Test_Link__c) and scripts/link.sh prints it so you can open it by hand. An SMS sender would text it at this step instead.
5. The caller types their email. They open https://<site>/typeback/?t=<token>, which loads the typebackForm Lightning Web Component on a guest site. TypebackFormController saves the email and sets the record to Submitted.
6. The caller says “done”. At the start of that turn, a router guard runs TypebackCheckAction before any LLM pass.
7. The agent reads back a masked hint. “I have an email starting with C, at example dot com. Is that right?”

The design rules

These are the rules that make it work. Keep them in mind if you change the code:

• The agent actions never throw and never return nulls. Every Typeback line the agent says is written in Apex and spoken word for word.
• Only the token’s SHA-256 hash is stored. The link carries a 128-bit random token, so a record can’t be used to rebuild its link.
• The agent user can’t read the typed value. The Typeback_Agent permission set has no access to Value__c, and an Apex test proves it.
• Send before saving. Apex can’t make a callout after DML in the same transaction.
• Links are tied to their call. The call Id comes from the agent’s VoiceCallId linked variable, never from what the caller says.
• Pull, not push. There’s no API to push an event into a live voice session, so the agent checks for the typed value on the caller’s next utterance.

Get the code

Everything in this tutorial runs from the agentforce-typeback repo on GitHub (Apache 2.0 license). Clone it and work from its root:

git clone https://github.com/ProstDev/agentforce-typeback.git
cd agentforce-typeback

Here’s what’s in it:

How to follow this tutorial (humans and AI agents)

Every step has one tag:

Doing it all by hand? Run the [AI] commands yourself, in order. Nothing in them needs an AI.

Handing it to an AI coding agent? Give it this page and a prompt like: “Follow this tutorial from Phase 0. Run the [AI] steps yourself. At each [HUMAN] step, stop, tell me exactly what to do, and wait until I say it’s done.” Also give it the rules below.

Rules for an AI agent

1. Stop at every [HUMAN] step. Say what to click, then wait. Don’t look for a scripted way around it.
2. Never do these without the person’s go-ahead at that moment: activate a site, get a phone number, register an SMS brand or campaign, send an email or SMS (even to the person), or delete anything in the org.
3. Keep secrets out of output. sf org display prints an access token, so use --json with jq and pick out only the fields you need. Never print tokens, session IDs or login URLs. Show phone numbers as their last four digits only.
4. Keep org details out of committed files: usernames, org IDs, domains and phone numbers. .env.local and org-reference/ are gitignored, so those details can go there.
5. Before any commit, put the agent user placeholder back: node scripts/setup-agent-user.js --username __AGENT_USER_PLACEHOLDER__
6. Live form links are bearer links. Don’t paste one anywhere public. It works until it’s used or it expires.
7. Run scripts by path, for example /bin/bash scripts/report.sh. Each one moves to the repo root and reads .env.local itself. Pass --json to sf commands in non-interactive shells, because their progress display floods logs otherwise.
8. Describe before you query. Some fields you’d expect aren’t queryable (for example MessagingChannel.SessionHandlerType and VoiceCall.IsVoiceMail). Check with sf sobject describe -o typeback -s <Object> --json | jq -r '.result.fields[].name'.

Prerequisites

The Salesforce org needs all of these (Phase 0 checks them):

• Agentforce, with Agentforce Service Agents
• Agentforce Voice (Agentforce Contact Center), with a way to get a phone number. My org’s entitlements included one 10-digit long-code number and inbound voice credits, so the number cost nothing.
• A free Einstein Agent User license, for the agent user
• Digital Experiences, for the guest site that hosts the form
• An admin login

I used an Enterprise Edition trial with these features on Summer ‘26 (API 67.0).

Your machine:

• Salesforce CLI 2.152 or later (check with sf --version), Node.js and jq
• Optional: qrencode (brew install qrencode), so scripts/link.sh can show the link as a QR code
• scripts/link.sh uses the macOS date -j. On Linux, change its date line to GNU date -d.

For the test calls: a real mobile phone on cellular data, plus a laptop next to it.

Overview of the phases

Phase 0: Connect the Salesforce CLI to your org

0.1 [HUMAN] Get an org that meets the prerequisites.

0.2 [HUMAN] Log the CLI in to it. Replace <your-domain> with your org’s My Domain:

sf org login web -a typeback -r https://<your-domain>.my.salesforce.com

Approve in the browser straight away, because the CLI only waits a few minutes (you’ll get an AuthTimeoutError if you’re slow). Use a browser window that’s already logged in to the org. If you get a username and password page instead, paste that tab’s URL into the window where you’re logged in.

0.3 [AI] Create the local config:

cp .env.local.example .env.local      # then set ORG if you used an alias other than typeback

0.4 [AI] Match the API version. Check the org’s API version without printing the access token:

sf org display -o typeback --json | jq -r '.result.apiVersion'

If it’s lower than sourceApiVersion in sfdx-project.json (67.0), set sourceApiVersion to the org’s version. Otherwise every retrieve fails with UNSUPPORTED_API_VERSION. A higher org version is fine.

0.5 [AI] Run the read-only recon:

scripts/recon.sh

It shows the edition, licenses, existing agents, routing flows, calls, sites and credentials, and it copies existing agents and routing flows into org-reference/. Look for:

• free Einstein Agent licenses
• the Omni-Channel Phone service channel
• whether Digital Experiences is on

Built-in routing flows show up by name but can’t be copied. That’s expected.

0.6 [AI] Check for a phone number entitlement:

sf data query -o typeback -q "SELECT MasterLabel, AmountUsed, CurrentAmountAllowed FROM TenantUsageEntitlement" --json |
  jq -r '.result.records[] | select(.MasterLabel | test("Long Code|Voice"; "i")) | "\(.MasterLabel): \(.AmountUsed // 0) of \(.CurrentAmountAllowed)"'

Mine showed one ten-digit long-code number and inbound voice credits. If you see nothing like that, [HUMAN] find out how your org gets a number before Phase 4.

Phase 1: Deploy the Apex, object and permission sets

1.1 [AI] Deploy and test:

scripts/setup.sh core

This deploys force-app, then runs the five Typeback test classes itself, because some orgs accept a RunSpecifiedTests deploy without actually running any tests. It also assigns you Typeback_Admin.

It worked when it prints 0 failed (I had 49 passing) and every Typeback class is at 75% coverage or more. Mine ranged from 86% to 100%.

Phase 2: Publish the guest site and the form

2.1 [HUMAN] Turn on Digital Experiences, but only if recon said it’s off. Go to Setup → Digital Experiences → Settings → Enable Digital Experiences, pick a domain, and click Save. Treat the domain as permanent.

2.2 [AI] Create and publish the site:

scripts/setup.sh site

It creates an empty “Build Your Own (LWR)” site at /typeback, publishes it, and assigns the site’s guest user Typeback_Guest. Site creation runs in the background and can take a few minutes. If publish fails because the site is brand new, wait a minute and re-run it.

It worked when it prints SITE_URL=https://<host>/typeback. Put that line in .env.local.

2.3 [AI] Write the settings:

scripts/configure.sh Log 10      # Log sender, links expire after 10 minutes, at most 3 links per call

2.4 [HUMAN] Activate the site, with its welcome email off. Go to Setup → Digital Experiences → All Sites → Typeback → Workspaces → Administration:

1. Under Emails, clear Send welcome email. Do this first: activating sends it to every site member.
2. Under Settings, click Activate.

This is a person’s step because it makes the site public and can email people.

[AI] check: this query should show Live:

sf data query -o typeback -q "SELECT Status FROM Network WHERE Name = 'Typeback'"

2.5 [HUMAN] Place the form. Go to All Sites → Typeback → Builder → Components (+) → Custom Components, drag Typeback Form onto the Home page, and click Publish.

2.6 [AI] Make a test link (nothing is texted):

scripts/new-link.sh

It prints a request name and a link. Each link works once and lasts 10 minutes. Links to one number are capped at 3 per 30 minutes, so for more, pass another fictional number: scripts/new-link.sh '415 555 0124'.

2.7 [HUMAN] Test the form on your phone, with Wi-Fi and any VPN off:

If the form shows “Something went wrong” as soon as you open a link, the guest user probably can’t run the controller. scripts/setup.sh tries to give the guest user Typeback_Guest (which grants it), but if that didn’t work: [HUMAN] In Builder → Settings → General, click the Guest User Profile link, then Enabled Apex Class Access → Edit, add TypebackFormController, and click Save.

Phase 3: Publish the Agentforce Voice agent

3.1 [AI] Set up, publish and activate the agent:

scripts/setup.sh agent

In order, it:

1. Creates an Einstein Agent user, or reuses the one already in the .agent file, and writes it into default_agent_user.
2. Assigns that user Typeback_Agent.
3. Validates, publishes and activates the newest version of TypebackDemoVoice.

It worked when it prints TypebackDemoVoice version N is active.

Then put AGENT_USER=<the printed username> in .env.local, so later runs reuse that user instead of using up another license.

3.2 [AI] Run the whole loop in a preview (live actions, Log sender, nothing texted):

scripts/preview-loop.sh

It plays a caller who:

1. Asks for an email, then gives a fictional number.
2. Says “done” too early and asks a side question.
3. Submits the form through the same controller the page calls.
4. Says “done”, confirms, and asks for a second email.

A second session backs out at the number prompt. The script checks each reply and the request row, and checks that the full email never appears in the preview traces.

It worked when the last line is PASS. Each preview turn takes 3 to 5 seconds.

A preview has no call, so the agent asks for a mobile number. On a real call it uses caller ID instead.

How the agent works

If you want to change the agent, here’s the shape of TypebackDemoVoice.agent:

• A router guard runs first on every turn. It clears tb_line first. Then, if a link is out (tb_waiting), it runs the check action and goes straight to the email_capture subagent, with no LLM routing pass.
• email_capture makes the link on entry, without the LLM, then says tb_line word for word.
• Its tools are gated with available when on tb_status: send_to_number, resend_link, skip_email and confirm_email.
• The resort facts live in the system instructions (check-in, spa hours and so on). They’re made up for the demo.

This is the router guard. It’s the part that makes the pull model work:

start_agent agent_router:
   reasoning:
      instructions:->
         set @variables.tb_line = ""
         # A link is out: check it and go straight to email_capture, with no routing pass.
         if @variables.tb_waiting:
            run @actions.router_check
               with voiceCallId=@variables.VoiceCallId
               with requestId=@variables.tb_request_id
               with cancel=False
               set @variables.tb_status = @outputs.status
               set @variables.tb_hint = @outputs.spokenHint
               set @variables.tb_line = @outputs.agentLine
               set @variables.tb_waiting = @outputs.waiting
            transition to @subagent.email_capture

Phase 4: Route a phone number to the agent

The agent must be active (Phase 3) before you start, so it shows up in the routing picker. I did all of this in Setup. Deploying the flow as metadata wasn’t tried.

4.1 [HUMAN] Get a number. Go to Setup → Agentforce Voice Setup → Voice Channels with Agents → New Number. A wizard opens in a new window:

1. Pick a country.
2. Number type: 10-Digit Long Code.
3. Pick a number.
4. Click Review & Save, then Finish.

The number shows as Requested, then Live within minutes. Use the Phone Numbers tab’s Refresh Status to check. Mine was free because of the org’s entitlement. If your org has none, check with whoever owns the org’s contract before you go ahead.

4.2 [HUMAN] Build the routing flow. Go to Setup → Flows → New Flow → Omni-Channel Flow.

1. The flow needs a Text variable named recordId, available for input. Salesforce passes the VoiceCall Id in it. Create it if the flow doesn’t have one.
2. Add one Route Work element:
   • Route a single record: recordId
   • Service Channel: Phone
   • Route To: Agentforce Service Agent → Typeback Demo Voice
   • Fallback queue: any queue (I used the contact center’s default queue)
3. Save it as Typeback Voice Routing, then click Activate.

The built-in voice routing templates are managed and can’t be retrieved to copy, so build this one from scratch. It’s only one element.

4.3 [HUMAN] Tie the number to the flow. Go to Setup → Agentforce Voice Setup → Voice Channels with Agents → New Channel. Choose PSTN Voice, your number and Typeback Voice Routing, then click Save.

4.4 [AI] Check the routing:

sf data query -o typeback -q "SELECT ApiName, IsActive FROM FlowDefinitionView WHERE ApiName = 'Typeback_Voice_Routing'"
sf data query -o typeback -q "SELECT DeveloperName, MessageType, IsActive FROM MessagingChannel"

It worked when the flow shows IsActive true, and there’s a PstnVoice channel with IsActive true.

Optionally, retrieve the flow read-only to check that it points at the agent. The output folder must be inside the project, and org-reference/ is gitignored:

sf project retrieve start -o typeback -m Flow:Typeback_Voice_Routing --target-metadata-dir org-reference/typeback-flow --unzip --json | jq -r '.status'

In the retrieved flow’s routeWork action, “Agentforce Service Agent” is saved like this:

Phase 5: Make a live test call

5.1 [AI] Start the link watcher in its own terminal, just before the call:

scripts/link.sh 300     # waits up to 5 minutes for the agent to make a link on a live call

It watches for a call in progress. As soon as the agent makes a link on it, the script prints the link, its expiry time and, if qrencode is installed, a QR code. This stands in for the text message.

5.2 [HUMAN] Make the call. Turn Wi-Fi off and use speakerphone, so you can type while you talk. Then call the number from your mobile. The first ring can take a while: that’s carrier time before the call reaches Salesforce, which accepted mine 4 to 5 seconds after it arrived.

Note the time you called, so you can match the call to its record.

5.3 [AI] Check the call:

scripts/report.sh 3

It lists the newest requests and calls, with phone numbers cut to their last four digits. It never reads the typed value. For the timings, run these, replacing <VoiceCall Id> with the Id from the first query:

sf data query -o typeback -q "SELECT Id, CreatedDate, CallAcceptDateTime, CallEndDateTime, CallDurationInSeconds, CallDisposition, VendorType FROM VoiceCall ORDER BY CreatedDate DESC LIMIT 1"
sf data query -o typeback -q "SELECT Status, ServiceChannel.DeveloperName, CreatedDate, AcceptDateTime FROM AgentWork WHERE WorkItemId = '<VoiceCall Id>'"
sf data query -o typeback -q "SELECT Name, Status__c, CreatedDate, Submitted_At__c, Retrieved_At__c FROM Typeback_Request__c WHERE Voice_Call_Id__c = '<VoiceCall Id>'"

The call passed when all of these hold:

• The call completed with no hang-up and no transfer.
• VendorType is VirtualVoiceAgent and the AgentWork is on sfdc_phone.
• The call’s FromPhoneNumber ends in your mobile’s last four digits.
• There’s one request row with that Voice_Call_Id__c, its status is Submitted, and Retrieved_At__c is set.
• The agent never said the full email.

Here are my timings from the second live call, counted from the start of the call record:

Phase 6: Clean up

• [AI] Before any commit, put the agent user placeholder back: node scripts/setup-agent-user.js --username __AGENT_USER_PLACEHOLDER__
• [HUMAN] The Twilio remote site setting: scripts/setup.sh core deploys all of force-app, which includes a remote site setting named Typeback_Egress_Check (it allows callouts to api.twilio.com). If you don’t plan to add a Twilio sender, delete it in Setup → Remote Site Settings → Typeback_Egress_Check → Del. Don’t use sf project delete source for this, because it deletes your local copy too.
• [HUMAN] To stop calls reaching the agent: deactivate the voice channel, or the Typeback Voice Routing flow. I found no way to release the number in Setup: the Phone Numbers tab only offers Refresh Status.
• [AI] To turn the agent off (after the person says so): sf agent deactivate -o typeback -n TypebackDemoVoice
• [HUMAN] The agent user: deactivate it in Setup → Users if you’re done with it.

Trial orgs expire. Nothing here depends on the org’s history, so in a new org you can start again from Phase 0.

What about texting the link by SMS?

Right now, the Log sender saves each link on its request row (Test_Link__c) instead of texting it, and scripts/link.sh prints it for you. I looked at two ways to send real texts. Neither is built yet.

• Native SMS on the same number. SMS is a separate messaging channel in Agentforce Contact Center (see “Create an SMS Channel in Agentforce Contact Center” in Salesforce Help). For a US 10-digit long code, you first register a 10DLC brand and campaign in Setup → Messaging → Regulatory Compliance. That’s where I stopped: Register Brand said “You need an active brand license to register a brand.” If your org has the license, the sending side would be the Send Conversation Messages action.
• Twilio. I confirmed the org can reach Twilio’s API, but didn’t build a sender. Keep in mind that a Twilio trial only texts verified numbers and adds a prefix to every message, toll-free numbers need verification before they can text US numbers, and US 10-digit numbers need A2P 10DLC registration.

To add a sender yourself:

1. Implement TypebackSms.Sender and return it from TypebackSms.sender(name).
2. Let scripts/configure.sh accept its name.
3. Keep the callout before any DML, and put credentials in a named credential, never in code or settings.

Troubleshooting: every problem I hit and the fix

“In the repo” means the fix is already in the scripts or code, so you’ll only hit it if you change them.

Salesforce CLI and project

The guest site

Apex and tests

The Agent Script agent

Here’s what I confirmed works in Agent Script on Summer ‘26, since the docs didn’t say:

• start_agent can have an actions: block.
• Inside instructions:->, run @actions.X with … set … followed by a bare transition to works.
• available when accepts and, not and !=.
• True and False literals work in bindings, and boolean Apex outputs map to booleans.
• The VoiceCallId: linked string variable with source: @VoiceCall.Id compiles, and it’s filled in on a real phone call.
• Preview with --use-live-actions runs the actions as the agent user.

Phone number, routing and calls

What’s not done yet

• Caller ID withheld. If the caller hides their number (*67 in the US), the agent should ask for a mobile number. That works in preview but I haven’t tried it on a live call.
• Edge cases on a live call: saying “done” too early, a side question, resends up to the cap, and a long silence while typing. The first two pass in preview and the cap passes in the Apex tests. Silence hasn’t been tried.
• A baseline: timing the same request with the email spelled out, to compare against Typeback.
• The expiry test on the form (Phase 2.7, last row).
• Automatic SMS: see texting the link by SMS.
• A transcript of the agent’s side of a live call.

If you rebuild Typeback in your own org and get further than I did (especially on SMS!), I’d love to hear about it :-)
