ACB deploys your app with the local port instead of 8092? Your properties are resolved at build time

Another one from the MuleSoft Community Slack workspace, and this is a great example of a bug that looks like an environment/config problem but is really a timing problem: when your properties get resolved.

The setup: someone uses ${https.private.port} for their HTTP listener port so that each environment can decide it. Locally they set https.private.port=1234. In PROD they deliberately leave it out of the config so CloudHub assigns the reserved internal port 8092 automatically. mule.env=PROD is passed on deploy. Straightforward, and it’s exactly how per-environment properties are supposed to work.

The problem: deploy the same app from Anypoint Studio and it comes up on 8092 as expected. Deploy it from Anypoint Code Builder (ACB) and it comes up on 1234, the local value, in CloudHub. Same code, same mule.env=PROD, two different results.

TL;DR

ACB resolves ${https.private.port} at build time, against your local config, and bakes 1234 into the packaged artifact. CloudHub then never re-resolves it in PROD, so it never falls through to 8092.

Anypoint Studio doesn’t hit this because it sets a runtime argument that forces a fresh parse of the config XMLs at deploy time. Add the same argument to ACB:

-Dmule.deployment.forceParseConfigXmls=true

Put it in ACB Settings under Mule > Runtime: Default Arguments. Redeploy, and the listener comes up on 8092 in PROD. It’s environment-agnostic, so you never have to touch it when switching between TEST and PROD.

The symptom

The tell is that the value being used is your local one, in a remote environment:

• Deploy from Studio → the listener binds to 8092 in CloudHub. Correct.
• Deploy from ACB → the listener binds to 1234 in CloudHub, even though PROD has no https.private.port defined and mule.env=PROD is set.
• The PROD config file genuinely has no https.private.port, on purpose, so CloudHub can assign the reserved internal port itself.

Because 1234 only exists in the local properties file, seeing it show up on a CloudHub worker is the whole clue. Something resolved that placeholder while your local config was still the active one.

The red herring: “it’s ignoring mule.env”

The natural first theory is that ACB isn’t passing mule.env=PROD to the runtime, so it loads the local config in CloudHub. That’s a reasonable guess, and it’s almost right, but not quite.

The environment isn’t being ignored at runtime. The issue is that the property was already resolved before the app ever reached CloudHub. By the time the runtime in PROD looks at the listener, the port isn’t a ${...} placeholder anymore. It’s a literal 1234 that got frozen into the artifact during packaging.

So chasing “how do I make ACB pass mule.env to CloudHub” sends you down the wrong path, because the runtime environment was never the problem. The build environment was.

The actual cause: properties resolved at build time

When ACB packages your app, it serializes a parsed application model as part of the artifact. This is an optimization, so the runtime doesn’t have to re-parse every config XML on startup. The catch is when the placeholders in that model get resolved: during packaging, against whatever configuration is active locally.

Locally, that’s your local properties file, the one with https.private.port=1234. So the placeholder resolves to 1234 right there on your machine, and that literal value travels inside the artifact all the way to CloudHub. In PROD, the runtime uses the pre-parsed model, sees 1234 already sitting there, and never re-resolves anything, so the platform-assigned 8092 never gets a chance to apply.

That also explains why leaving https.private.port undefined in PROD looks fine but doesn’t help: the runtime isn’t reading your PROD config for that value at all. It’s reading a decision your local machine already made.

Why Anypoint Studio gets it right

Here’s the part that makes it click. Studio sets this in its default runtime arguments, out of the box:

-Dmule.deployment.forceParseConfigXmls=true

That flag tells the runtime to re-parse the configuration XMLs at deployment time rather than trusting a pre-parsed model. With it on, ${https.private.port} stays a real placeholder until it’s resolved in the target environment, so in PROD it resolves against the PROD config, finds nothing, and correctly falls through to the platform’s 8092.

ACB doesn’t set that argument by default. Same code, same mule.env, but one tool defers property resolution to deploy time and the other doesn’t. That single default is the entire difference.

The fix

Add the same argument to ACB so it re-parses the config at deploy time:

1. Open ACB Settings.

2. Find the Mule > Runtime: Default Arguments section.

3. Add:

   -Dmule.deployment.forceParseConfigXmls=true

4. Redeploy.

Now ${https.private.port} is resolved in the target environment. In PROD it’s undefined, so CloudHub assigns 8092. Locally it’s 1234. Each environment decides its own port again, which was the whole point of using the placeholder.

The nice thing about this fix is that it’s environment-agnostic. It doesn’t pin the app to PROD, so you can deploy to TEST or PROD without editing anything.

The other fix that works (and its catch)

While troubleshooting, another approach also worked: adding mule.env=PROD as a property in mule-artifact.json and deploying. That fixes it for a subtly different reason. It makes the PROD config active at build time, so when ACB resolves placeholders during packaging, https.private.port is already undefined and never gets frozen to 1234. The value stays open and CloudHub assigns 8092.

The catch is right there in how it works: it hardcodes the environment into the artifact. If you also deploy to TEST, you’d have to change mule.env in mule-artifact.json every time, which is exactly the manual juggling you were trying to avoid by using per-environment properties.

Quick recap

• If a CloudHub app deployed from ACB uses a value that only exists in your local properties file, the placeholder was resolved at build time, not at deploy time.
• ACB serializes a pre-parsed application model during packaging and resolves ${...} placeholders against your local config, baking the local value into the artifact.
• Anypoint Studio avoids this because it sets -Dmule.deployment.forceParseConfigXmls=true by default, forcing a fresh parse at deploy time.
• Add that same argument to ACB under Mule > Runtime: Default Arguments. It’s environment-agnostic, so one build deploys to any environment and each resolves its own properties.
• Setting mule.env in mule-artifact.json also works, but it hardcodes the environment into the artifact, so you’d have to change it per deploy.

I hope this was helpful.

💬 Prost! 🍻
